| FOB Price: | sent inquiry to us |
| Brand Name: | Taida |
| Model Number: | Can be customized |
| Mininum Order Quantity: | 1SET |
| Supply Ability: | 10 sets per month |
| Delivery Time: | 25 days |
Cone ball mill
1.for cement, silicate, ceramic
2.wet or dry ball mill
3. Overflow or grate ball grinder
4.ISO CERT
Cone Ball Mill introduction:
Cone Ball Mill is a key equipment to grind the crushed materials, and the ball mill is widely used in powder-making production line including cement, silicate, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and non-ferrous metal, glass ceramics, etc, and the ball mill can grind various ores and other materials with dry type and wet type. There are two kinds of ball mill, grate type and overfall type due to different ways of discharging material.Energy-saving Cone Ball Mill
This Cone Ball Mill changes the intrinsic grinding machine structure. Ball mill body and ground plank are an integral whole, so when fixing ball mill can be lowered on a plane surface once only. Using double tiered roller axletree with centripetal spherical surface as the support of the host axletree can reduce energy cost by 30%.The intrinsic grille pattern forcing evacuation of ball mill is instead by overfall pattern controlling one. ball mill can improve the milling of the granule and the capacity of the ball mill be increased by 15-20%.
Advantages of Cone Ball Mill:
1 Ball mill's Double-row self-aligning spherical roller bearing replaces babbit-lined bearing. Friction resistance is greatly lowered down, easy to start and 20-30% of energy is saved.
2. Ball mill's Grooved and ringed liner increases contacting surface between balls and ores, improving milling effect and saving energy through its lifting effect to the materials.
3. Ball mill's All-in-one frame is used in middle-sized or small-sized machinery, facilitating engineering construction and equipment installation.
4. Ball mill's large discharging outlet and high capacity, discharge coarse particles, usually used in first stage milling.
5. The Energy-saving Cone Ball Mill can be used for grinding particles in the process of metal mineral resouces, such as gold, silver, iron, copper, lead, zinc etc., and non-metal mineral resources.
Technical data of Cone ball mill:
|
Model and specification |
Shell Rotation Speed(r/min) |
Ball Load (t) |
Feed size (mm) |
Discharge size(mm) |
Capacity (t/h) |
Power (kw) |
Weight (t) |
| Φ800×1800 | 38 | 1.5 | 0-15 | 0.075-0.8 | 0.3-0.8 | Y11-4 | 2.1 |
| Φ900×2100 | 38 | 2 | 0-15 | 0.075-0.8 | 0.5-1.3 | Y15-4 | 3.2 |
| Φ1200×2800 | 35 | 4.8 | 0-20 | 0.075-0.8 | 1.2-3.7 | Y30-6 | 11.5 |
| Φ1500×3500 | 28 | 8 | 0-25 | 0.075-0.8 | 3.3-8.8 | Y55-75-6 | 16.5 |
| Φ1830×3500 | 25 | 13 | 0-25 | 0.075-0.8 | 4-8 | Y150-6 | 30 |
| Φ2100×2700 | 24 | 15 | 0-25 | 0.075-0.8 | 3.5-25 | Y150-8 | 33 |
| Φ2100×3500 | 24 | 20 | 0-25 | 0.075-0.8 | 4.533 | Y180-8 | 37 |
| Φ 2200×7000 | 21 | 24 | 0-25 | 0.075-0.8 | 8-36 | Y380-8 | 50 |
