Metallurgy rotary kiln
FOB Price:     sent inquiry to us
Brand Name:     Taida
Model Number:     Can be customized
Mininum Order Quantity:     1SET
Supply Ability:     10 sets per month
Delivery Time:     25 days

buy   email

features of Metallurgy rotary kiln

1.simple structure

2.power saving

3.low pollution

4,high capacity

Discription of Metallurgy rotary kiln

Rotary metallurgy Kiln is commonly used for heat processing of minerals and aggregates such as lime, cement, and iron ore. To achieve consistent quality results, it is important to maintain a uniform product temperature at the kiln entry, mid zone, and discharge. In most rotary kilns, the challenge with temperature process control is that the temperature sensor must view through flames or heavy smoke and dust. Consequently, when selecting a sensor, the design, wavelength, and alignment are all important considerations.

Technical data of Metallurgy rotary kiln

Size （m） Capacity （t/d） Main Motor Main Reducer Weight
（t）		 Remark
Model Power(Kw) Model Speed ratio
φ18x26 72 JZT2-72-4 30 JZQ750-1-Ⅰ  48.57 66
φ1.9/1.6x39 72 JZT2-72-4 30 JZQ750-1-Ⅰ  48.57 66
φ1.9x36 84 YCT315-4A  37 ZS110-5-Ⅲ 78.19 85.9
φ2.2x45 98.4 JZT82-6 55 ZA125 93.93 104
φ2.5x40 160 Z2--92 40 ZS125-2-Ⅰ 134.9 143
φ2.5x45 170 JTZ82-4 45 ZS125-4-Ⅰ 69.71 148
φ2.5x50 180 ZT3-72-4 30 ZS145-9-Ⅴ 122.8 173
φ2.5x60 168 YCT355-4B 75 ZS165-7-Ⅱ 99.96 222 Bauxite Calcining Kiln
φ3x48 360-480 YCT355-4B   75 ZS145-7-Ⅱ 100.4 170.6
φ3.1/2.5x78 216-240 Z4—225-31 75 ZS165-2-Ⅱ 57.17 268
φ3x48 700 ZSN4-280-21B 110 MSY56-28-Ⅱ 28 244 Decomposition outside kiln
φ3x100.94 450 ZSN4-280-21B 90 NZS995-90-Ⅵ-L 90 526 Planetary cooling?
φ3.2x50 1000 ZSN4-280-21B 160 MSY56-28-Ⅱ  28 252.4 Decomposition outside kiln
φ3.2x52 600 ZSN4-280-21B 125 ZSY1110-71BL 71.54 275 Pre-heater Kiln
φ3.3x52 1000 ZSN4-280-11B 125 NZS995-40-Ⅵ-BR 40 283 Decomposition outside kiln
φ3.5x52.5 1400 Z2-112      180 ZS177  79.22 360 Decomposition outside kiln
φ3.5x54 1500 ZSN4-3156-092 220 ZSY500-40-Ⅴ 40 368 Decomposition outside kiln
φ3.6x70 490 ZSN4-280-11B 125 ZS177-5-Ⅱ 79.2 419 Electricity Generation Kiln with remaining heat
φ3.95x56 2000 Z4-280-32BTH 250 ZSY560-40-Ⅰ 40 417 Decomposition outside kiln
Φ4x28 90 ZSN4-280-21B 160 ZSY500-71-Ⅳ 71 300
φ4x60m 2500 ZSN4-355-09Z  315 ZSY630-35.5-Ⅰ  34.6 523 Decomposition outside kiln
φ4.2x60m 2800 ZSN4-355-12 420 ZSY710-35.5-Ⅰ  35.5 --- Decomposition outside kiln
φ4.3x60m 3000 ZSN4-355-12 375 ZSY710-40 40 553 Decomposition outside kiln
φ4.8x75m 5000 ZSN4-400-92 630 JH710-40 42 841 Decomposition outside kiln
