    Monocular Cooler

Inquiry Online


Monocular cooling machine is the main marching equipment for rotary kiln production system or rotary dryer system

Its structure is simple, performance stable and operation is reliable

The waste gas produced by heat exchange will be imported into rotary kiln to improve the thermal efficiency of the whole system

technical specification


Type (mm)		 Indiclination (%) rotation speed (r/min) Output (t/h) motor power (kw) Dimension (mm) Weight（kg）
TDLQΦ800×12000 4 4.98 0.4-0.8 5.5 12300×2020×1920 7455
TDLQΦ1000×12000 5 5.03 1.0-2.0 7.5 12000×2121×1903 12580
TDLQΦ1200×12000 4 5.03 2.0-3.0 4 12000×2277×2318 15986
TDLQΦ1200×15000 4 5.99 2.5-3.5 11 15000×2277×2318 18732
TDLQΦ1500×12000 3.5 4.01 3.5-4.8 15 12000×2935×2910 20644
TDLQΦ1500×15000 3.5 4.01 3.8-5.2 15 15000×2935×2910 21976
TDLQΦ1800×18000 3.5 3.5 5.0-7.1 22 18000×3510×3580 58600
TDLQΦ2000×20000 3.5 3.44 8.0-10 30 20000×3810×3820 61100
TDLQΦ2000×22000 3.5 3.44 8.5-10.5 30 22000×3810×3820 62632
TDLQΦ2200×22000 3.5 3.44 10-12.5 30 20000×4110×4120 88610
TDLQΦ2500×22000 3.5 3.52 11-14 55 24830×4680×6020 108780


Relevant cases：

  • Sludge Alkaline Stabilization D

    Sludge lime disposal project in Yanjiao sewage plant Yanjiao sewage treatment plant is located in the southwest of Yanjiao Development Zone. The project site is located in Yanjiao sewage plant in the northwest corner of processing, on the west side of...
  • Heavy Metal Sludge Dehydration

    Brief introduction of process flow 1.Collection and transportation of sludge: trained personnel to clients collected sludge with iron and space bag packaging, and by the special transport of dangerous goods vehicle transport to the factory dangerous g...
