    Pendulum feeder



It is suitable for concentrating coal chemical industry and other departments, makes the grain delivery to various set of accepting the material from the store chute by the filter

The pendulum feeder is not suitable for delivering the dry power of the too big material or else, it may appear the fly-ash pollution or the jam of the output

Technical parameters


Product name
Pendulum feeder Pendulum feeder
Product size 400*400 600*600
Swing t imes(times/min) 47 45.8
Output size(mm) Width 400 600
Height 400 600
Swing journey(mm) 0-170 0-220
Max feeding size(mm) 35 50
Capacity(t/h) 0-12 3-25
Motor Type Y90S-4 Y100L-4
Power(kw) 1.1 2.2
Total weight(kg) 269 558
