| FOB Price: | sent inquiry to us |
| Brand Name: | Taida |
| Model Number: | Can be customized |
| Mininum Order Quantity: | 1SET |
| Supply Ability: | 10 sets per month |
| Delivery Time: | 25 days |
Introduction
For raw materials with heavy humidity which is above 12%, you need to install a dryer before further processing
This air current type dryer can reduce the humidity of wood materials below 12% per time
The cost of this air current dryer is much lower than rotary dryer
It is professionally designed for drying different kinds of wood sawdust
It has advantages of low cost, low consumption, high capacity, easy operation and maintenance, and more
In addition, the round places of pipes can be changed to any angle which can save space and solve plant dimension limitation
Mechanical structureand working principle:
Regarding TDS-I and TDS-II type dryer (with one stove), it is suitable to process materials which moisture content between 20 to 25%
It can reduce the MS to 8 to 12% one drying time
Regarding TDS-III (with two stoves), it is suitable to process materials which moisture content between 35 to 50%
It can reduce the humidity to 8 to 12% one drying time
That means it can reduce approximately 30% for one drying time
But if the humidity of materials is lower than 35%, the capacity will be increased with less of fuel
All of round places can be adjusted to any angle of 360 centigrade degree according to operation request
Clients can change the angle of dryers base on the production field
Technical Specification:
|
Model |
TDS-I Type dryer with one stove |
| Capacity (Kg/hour) | 200-300 |
| Size of Input material (Diameter) mm | < 3 & < 5 |
| Temperature of Hot Air | 180°C~250°C |
| Power (Kw) | 4 |
| Gross/Net Weight (Kg) | 1300/1200 |
| Overall Dimension (L*W*H) m | 10*1.0*2.0m |
| Packing Dimension (mm) | 2440*1220*2150 |
