    Slag dryer

Inquiry Online


High drying capacity

Steady running

Low energy consumption

Convenient operation

High output

Technical Specification


Item
Specification		 Shell inner dia. Shell length Slope
0		 Rotating speed
r/min		 Flow Motor power
kw		 Output t/h Inlet moisture Outlet moisture Inlet hot air temp. Outlet hot air temp. Weight
t
φ1.5×12m 1500 12000 2.0 3.4   15 ∼4 15∼10% 1∼30% 800∼7000c 150∼900c 19.6
φ1.8×15m 1800 15000 2.0 4.04 18.5 ∼6.5 25
φ2.2×14m 2200 14000 2.0 3.68 37 ∼11 44
φ2.2×18m 2200 18000 2.0 2.9 37 ∼12 48
φ2.4×18m 2400 18000 2.0 3.27 45 ∼16 56
φ2.6×24m 2600 24000 2.5 3.2 55 ∼22 72.5
φ2.8×24m 2800 24000 2.0 3.4 55 20-40 87
φ3.0×20m 3000 20000 2.29 3.1 75 25-60 105
φ3.0×25m 3000 25000 2.29 3.2 75-90 35-80 125
φ3.2×25m 3200 25000 2-2.29 4.14 90-132 60-150 155
φ3.4×28m 3400 28000 2-2.29 3-4.1 110-132 70-150 162
φ3.6×28m 3600 28000 2.0 2.6-4 160-200 80-155 168


Relevant cases：

  • Sludge Alkaline Stabilization D

    Sludge lime disposal project in Yanjiao sewage plant Yanjiao sewage treatment plant is located in the southwest of Yanjiao Development Zone. The project site is located in Yanjiao sewage plant in the northwest corner of processing, on the west side of...
  • Heavy Metal Sludge Dehydration

    Brief introduction of process flow 1.Collection and transportation of sludge: trained personnel to clients collected sludge with iron and space bag packaging, and by the special transport of dangerous goods vehicle transport to the factory dangerous g...
