    Double roll crusher



Introduction:

Used for middle crushing and fine crushing of all kinds of ore and rocks under mid-hardness in mineral dressing, chemistry, cement, building materials and other industrial sections

Characteristics:

Reliable operation

Easy maintenance

Low operating costs

Adaptable feed granularity

Technical specification:


 Type
2PG400×250 2PG610×400 2PGC450×500 2PGC600×750
Roller diameter(mm) 400 610 450 600
Roller length(mm) 250 400 500 750
Max marerial-in size(mm) ≤25 ≤85 ≤100—200 ≤300—600
Material-out size(mm) 2—8 10—30 25—100 50—125
capacity(t/h) 5—10 13—40 20—55 60—125
Roller number 2 2 2 2
Roller speed (r/min) 180 75 64 50
Pure weight 1.1 3.5 3.8 8.34
Overall size(l×w×h)(mm) 1215×834×830 2235×1722×810 2260×2200×766 2780×3065×1310
Assorted motor Type Y160L—6 Y225M—6 Y160L--8 Y180L--8 Y225M—8
power(kw) 11 30 7.5 11 22
