Fine crusher
FOB Price:     sent inquiry to us
Brand Name:     Taida
Model Number:     Can be customized
Mininum Order Quantity:     1SET
Supply Ability:     10 sets per month
Delivery Time:     25 days

buy   email

Discription of fine crusher:

The PXJ 800 x 400, 800 x 600, 800 x 800, and 1,000 x 1,000 crusher series are our third generation of sand making machines

They are new high efficiency sand making equipment, which were developed according to the feedback of our users, referring to the working principles and advantages of various crushers

A typical use is to adapt to the current mechanism of sand industry and substitute of rod-mill sand maker, impact sand maker, and straight processing sand maker

Features:

Small material size, uniform granularity, large production capacity, long lifespan hammer, supporting small power, and change three for two broken, process simplification, simple structure, easy maintenance, and the smooth running characteristics

Equipment investment lower than the same size of the traditional technique and equipment

35 to 50%, higher than the same scale output efficiency of traditional technique and equipment 35 to 50% (limestone as an example: one product size ≤5 mm accounting for 85 percent)

Long-term maintenance costs run less than the same size of the traditional technique and equipment 35 to 50%, widely used mechanism aggregate, cement, refractories, and metallurgical industries

Technical Data


PXJ crusher		 Rotor width ø×(mm)
type 800×400 800×600 800×800 1010×1010 1200×1000 1200×1200 1400×1400 1600×1600 1800×1800
Material-in size(mm) 400×185 500×250 550×330 1000×350 1200×400 1200×450 1500×500 1600×550 1800×800
Material size(mm) <120 <180 <180 <180 <180 <180 <190 <190 <190
Material-out size(mm) <5 <5 <5 <5 <5 <5 <5 <5 <5
Materual-out ajustment 5-20 5-20 5-20 5-20 5-20 5-20 5-20 5-20 5-20
Cement clinker（T/H） 20-30 35-40 35-45 45-55 80-110 100-110 100-150 170-210 250-270
Lime stone（T/H） 35-45 45-55 55-65 65-75 50-100 90-100 100-150 190-250 280-310
Power（KW） 37-45 45-55 45-55 55-75 100-110 100-132 160 250 315
