    Mixing barrel



Driven by V-belt drive motor rotating impeller

Drugs and medicines and pulp slurry are mixed uniformly and sufficiently, which increases reaction time and strengthen the reaction quality of pharmaceutical drugs

Applies to mineral dressing industry, as well as mixing of chemical ingredients

Specifications of mixing barrel


Specification
Chute inner dimension Effictive cubage Mixer Motor Weight(kg)
Diameter(mm) Depth (m3) Diameter(mm) Rotate speed(r/min) Model Power(kw)
(mm)
XB-750 750 750 0.26 240 530 Y90S-4 1.1 228
XB-1000 1000 1000 0.58 240 530 Y90L-4 1.5 436
XB-1200 1200 1200 1.14 400 320 Y100L2-4 3 765
XB-1500 1500 1500 2.2 400 320 Y100L2-4 3 1083
XB-2000 2000 2000 5.46 550 230 Y132M2-6 5.5 1671
XB-2500 2500 2500 11.2 650 200 Y160L-6 11 3438
XB-3000 3000 3000 19.1 700 210 Y225S-8 18.5 4613
XB-3500 3500 3500 30 850 230 Y225M-8 22 71
