It is suitable for concentrating coal chemical industryand other departments, makes the grain delivery to various set of accepting the material from the store chute by the filter. The pendulum feeder is not suitable for delivering the dry power of the too big material or else, it may appear the fly-ash pollution or the jam of the output.

Technical parameters of Pendulum feeder

Product name			Pendulum feeder	Pendulum feeder
Product size			400*400	600*600
Swing t imes(times/min)			47	45.8
Output size(mm)		Width	400	600
		Height	400	600
Swing journey(mm)			0-170	0-220
Max feeding size(mm)			35	50
Capacity(t/h)			0-12	3-25
Motor	Type		Y90S-4	Y100L-4
	Power(kw)		1.1	2.2
Total weight(kg)			269	558
