Biomass Burner

Thermal power value: 30 to 240 kcal
Applications: it is applied to production industries such as metallurgy, drying, chemistry, building materials, refractory materials and fertilizer.
Materials: non-caked and weak bonding bitumite and anthracite;
Product introduction: biomass burner is a kind of biomass semi-gasification automatic control burner. It is a high-temperature cracking burner which regards biomass as fuels.

Sales Hotline:

0086-18539990967

Technical introduction

Biomass burner is a kind of biomass semi-gasification automatic control burner. It is a high-temperature cracking burner which regards biomass as fuels.
ZY-S series biomass burner is a combination product of our company and famous universities and scientific research institutions.combining with our company’s real situation, we absorb foreign advanced experience. Aimed at the special features of biomass fuels, we design and develop biomass burning equipment by using cheap biomass particles. This product adopts semi-gasification compound combustion technology. It is characterized by reasonable structure, automatic intelligent control, Chinese LCD interface, remote operation interface, automatic switching, automatic feeding, high thermal efficiency, full combustion, no pollution, less emission, compact structure, simple installation less covering area and less running cost. It can save about 30% to 60% running cost than using oil and gas.
Applications:
Biomass burner is widely applied to boiler, die casing machine, industrial kiln, incineration furnace, melting furnace, kitchen equipment, drying equipment, food drying equipment, ironing equipment, baking equipment, highway construction machinery equipment, industrial annealing furnace and asphalt heating equipment.

Advantages

1. High efficiency and energy saving: use renewable biomass particles as energy; less utilization cost; it can save about 30% to 60% running cost comparing with using oil;
2. Stable and reliable: micro negative pressure running; no backfire and blow-off;
3. High thermal efficiency: semi-gasification compound combustion matches with tangential vortex distribution design;  low temperature and staged combustion;
4.  Low carbon and friendly to environment: low emission of smoke and sulfur nitrogen; no carbon dioxide emission; meet the GB13271 smoke emission standard;
5. Simple operation: adopts air cooled protection; simple installation, automatic feeding, simple operation. Less labor force; single person on duty is OK.
6. Utilization of hot water: water cooled structure; hot water produced can be used for production or domestic application;

Working principle

Running cost check list of biomass burner and advantage analysis
Taking 50 kilocalorie as an example, running cost of fuels is following (for your reference);
Fuel kinds (kcal/kg)
Thermal value
Utilization efficiency Market price Amount consumed Running cost
Diesel 1.0 to 1.1 ten thousand about 50% 7.5yuan/kg 100kg 750yuan
Natural gas 8500/standard square about 60% 4.8yuan/kg 100spruare meters 480yuan
Industrial power 860/°C about 90% 1yuan/°C 64kw/h 640yuan
Coke 6000~7000 about 45% 1800yuan/ton 180kg 324yuan
Wooden particle 4200~4800 about 50% 1000yuan/ton 240kg 240yuan


Technical parameters

Model Kcal
Thermal power
kg/h
Unit energy consumption
Packing size m kg
ZY-S30 30 50~75 1.8*0.8*1.0 500
ZY-S45 45 80~110 1.9*1.0*1.2 700
ZY-S60 60 90~150 2.0*1.0*1.3 1000
ZY-S90 90 160~225 2.4*1.5*1.3 1300
ZY-S120 120 220~300 2.6*1.5*1.5 1500
ZY-S240 240 350~600 2.8*1.8*1.9 2000
