    Rice Husk Dryer



rice husk dryer:

300~400kg/h capacity

4kw power

CE certification

material can be powder,sawdust,straw,rice husk

Rice husk dryer is suitable for drying materials like sawdust, rice hull, milling wheat straw, corn stalks and so on. The moisture of wet materials is at 20-30%.

The rice husk dryer is equipped one fuel boiler, inlet, steel pipe, exhaust blower (fan), cyclone. Wet materials are input into the hopper. The fuel boiler generates hot air which mixes with wet materials and then is sucked into the pipes by the exhaust blower (fan) quickly. And then hot air is flowing and going though the curving pipes and buffer (drying chamber) of dryer, thus wet materials is finished to dry, and the dried materials are expelled out by the exhaust blower (fan).

This rice husk dryer reduces the moisture to 8-12% with the advantages of lower cost consumption and high efficiency.

Technical Data:


Model
HJ-I HJ-II HJ-III HJ-IV
Number of motors 1 3 3 3
Power 4 7.5+0.75+0.75 11+0.75+0.75 15+0.75+0.75
Capacity 300-400 500-600 700-800 1000-1200
Diameter of materials <1mm & < 5mm <1mm & < 5mm <1mm & < 5mm <1mm & < 5mm
Gross Weight(kg) 1100 2260 3080 3120
Consumption of wood waste(kg/h) 10-15 15-20 20-30 25-35
Overall dimension( m )(length*width*height) (space required) 7*2*4 9*2*4 12*2.5*4 12*2.5*4
Shpping size(m3) (2 pcs)
1.5*1.06*1.1
2.44*1.22*1.55
(3 pcs)
1.23*1.24*1.73
1.5*1.06*1.1
2.44*1.22*2.1
(3 pcs)
1.23*1.24*1.73
1.45*1.42*1.41
2.45*1.72*1.91
(3 pcs)
1.38*1.3*1.8
1.6*1.5*1.5
2.53*1.8*2.0
Working Temperature 400 °C 400 °C 400 °C 400 °C
No need to use other gauges fitted
