    Vegetable Dryer

Inquiry Online


Vegetable Dryer

1.High vegetable drying efficiency

2.Device configuration flexibility

3.Large vegetable handling capacity

Vegetable Dryer Introduction:

Mesh belt dryer is commonly used in continuous drying equipments. The mesh belt dryer can be widely used in chemical, pharmaceutical, food, building materials, electronics and other industries.

Vegetabledryer is especially suitable for a better ventilation sheet, strip, granular materials drying. And mesh belt dryer is also available for drying after the paste materials forming through the mechanism of granulator.

Vegetable Dryer Features and Characteristics:

1.Mesh belt dryer can adjust air volume, heating temperature, materials residence time and feeding rate of materials in order to obtain the best possible drying effect.

2.Equipments are configurated flexibility, the mesh belt dryer can use the belt cleaning system and material cooling system.

3.Most of the air can be recycling, and high energy saving.

4.Unique air distribution device ensures products quality consistency.

5.Heat source can adopt steam heat transfer oil or gas-fired hot blast stove configuration.

Vegetable Dryer Technical Parameter:


Type		 DWT1.6-I
(fed table)		 DWT1.6-II
(middle table)		 DWT1.6-III
(discharge table)		 DWT2-I
(fed table)		 DWT2-II
(middle table)		 DWT2-III
(discharge table)
belt width m 1.6 1.6 1.6 2 2 2
drying section length m 10 10 8 10 10 8
thickness of the material to be covered mm ≤100 ≤100 ≤100 ≤100 ≤100 ≤100
temperature 50-150 50-150 50-150 50-150 50-150 50-150
Areae of heat conduction m2 525 398 262.5 656 497 327.5
steam pressureMpa 0.2-0.8 0.2-0.8 0.2-0.8 0.2-0.8 0.2-0.8 0.2-0.8
drying time h 0.2-1.2 0.2-1.2 0.2-1.2 0.2-1.2 0.2-1.2 0.2-1.2
power kw 0.75 0.75 0.75 0.75 0.75 0.75
overall Dim.m 12×1.81×1.9 12×1.81×1.9 10×1.81×1.9 12×2.4×1.92 12×2.4×1.92 10×2.4×1.92
