Vibrating feeder
FOB Price:     sent inquiry to us
Brand Name:     Taida
Model Number:     Can be customized
Mininum Order Quantity:     1SET
Supply Ability:     10 sets per month
Delivery Time:     25 days

buy   email

Vibrating feeder can feed block or granule materials from the material storage to charging device evenly and continuously

It can realize even feeding for crushers in sandstone production line and make rough screening for materials

Widely applied in combined operation of crushing and screening in the industries like metallurgy, mine, mine selection, building materials, chemicals, and more

Features:

Stable vibrating, reliable operation, and long lifespan

Can adjust the excitation force and change and control the flow stably and conveniently

With low noise, small power consumption, good adjusting performance, and without material splash

Simple structure, reliable running, convenient installation, lightweight, small size, easy maintenance, and the enclosed type can prevent dust pollution

Main technical parameters of Vibrating feeder


Model		 Max. feeding (mm) Pocessing capacity(t/h) Motor power(kw) Obliquity of material trough Total weight(kg) Trough size (mm) Dimensions (L*W*H)(mm)
GZD-850*3000 400 120 3.7*2 5 3607 850*3000 3110*1800*1600
GZD-1000*3600 500 150 5.5*2 5 3895 1000*3600 3850*1950*1630
GZD-1100*4200 580 240 5.5*2 5 4170 1100*4200 4400*2050*1660
GZD-1100*4900 580 280 7.5*2 5 4520 4900*1100 5200*2050*1700
GZD-1300*4900 650 450 11*2 5 5200 4900*1300 5200*2350*1750
ZSW-380*95 500 96-160 11 0 4082 3800*960 3920*1640*1320
ZSW-490*110 630 120-280 15 0 5352 4900*1100 4980*1830*1320
ZSW-600*130 750 400-560 22 0 7800 6000*1300 6082*2580*2083
