    Iron powder ball press machine




Specifications

1.High quality and efficiency
2.Long service life
3.Low-consumption
4.Ball press with ISO9001:2000

Ball press machine application:

Ball press machine is mainly used for high-density metal scrap (scrap iron, copper scrap, aluminum scrap, etc.), granular powder metal powder (iron powder, aluminum powder, copper powder, lead powder, etc.) , metallurgical additives, sponge iron, etc., without adding any binder pressed into the case of cylindrical cakes of high-density block (weight 2-8 kg), the cake density of up to 5T/M3 block above (the different raw materials, press out the cake block density and not quantity is not the same), pressed into the cake pieces can be directly cast furnace use.

Ball press machine Features:
1. High quality and efficiency
2. Long Service life
3. Low-consumption,energy saving

Working Principle:

This series of ball press machine will pass the power on to the two pressure roller through the reducer.The two sides and roll rotation, in both the rotating roll,Natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger, When the material to the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials become a finished product from the powder ball.

After-sale services:

1. We will supply the most suitable crushing plant to customers according to their requirements.

2. Assist clients to prepare for the first construction scheme, we will supply the Machine Base drawing and Installation manual.

3. For the Installation, we will dispatch two or three engineers to guide the installation, take the trial test, train their worker, debug the equipment, adjust the capacity etc if you need.

4. The regular inspection and maintenance will be supplied on time.

Main Technical Parameter:

Model

Reducer

speed ratio

The dimension of pressing roll

speed of main shaft(r/min)

Power of motor

(kw)

Output

(t/h)

TD360-4

ZQ350

1:31.5

Φ360*250

15-17

7.5

3-5

TD 360-2

ZQ350

1:31.5

Φ360*250

15-17

7.5

3-5

TD 400-4

ZQ400

1:31.5

Φ400*250

15-17

11

4-7

TD 400-2

ZQ400

1:31.5

Φ400*250

15-17

7.5

4-7

TD 430-4

ZQ400

1:31.5

Φ430*250

15-17

11

5-8

TD 430-2

ZQ400

1:31.5

Φ430*250

15-17

7.5

5-8

TD 500-4

ZQ500

1:31.5

Φ500*350

15-17

22

8-10

TD 500-2

ZQ500

1:31.5

Φ500*350

15-17

15

8-10

TD 650-4

ZQ650

1:31.5

Φ650*350

15-17

30

12-20

TD 650-2

ZQ650

1:31.5

Φ650*350

15-17

22

12-20

TD 750-4

ZQ750

1:31.5

Φ750*380

14-16

30

4

25-30

TD 850-4

ZQ850

1:31.5

Φ850*436

14-16

37
 4

35-40

TD 1000-4

ZQ1000

1:31.5

Φ1000*530

14-16

45
 4

40-45
