    Rotary dryer

Inquiry Online


Discription of rotary dryer

Rotary dryer, also known as rotary drum dryer

Widely used in building materials, metallurgy, chemicals, industrial drying slag cement limestone, coal, slag, clay and other materials

The aircraft mainly by the rotary, jan plate, transmission, seals, and other support equipment and components

With a reasonable structure, well-produced, high yield, and low consumption, the advantages of operating convenience

Plant products quality assurance, highest free installation debugging agent can be checked with other plants than quality and prices

Technical Specification


type(mm)		 indiclination(%) rotation speed(r/min) input tempreture(ºC) motor power(kw) outpur(t/h) weight(t) reforance
Φ600×6000 3-5 3-8 ≤700 3 0.5-1.5 2.9
Φ800×8000 3-5 3-8 ≤700 4 0.8-2.0 3.5
Φ800×10000 3-5 3-8 ≤700 4 0.8-2.5 4.5
Φ1000×10000 3-5 3-8 ≤700 5.5 1.0-3.5 5.6
Φ1200×10000 3-5 3-8 ≤700 7.5 1.8-5 14.5
Φ1200×12000 3-5 3-8 ≤700 11 2-6 14.8
Φ1500×12000 3-5 2-6 ≤800 15 3.5-9 17.8
Φ1800×12000 3-5 2-6 ≤800 18 5-12 25
Φ2200×12000 3-5 1.5-6 ≤800 18.5 6-15 33
Φ2200×18000 3-5 1.5-6 ≤800 22 10-18 53.8
Φ2200×20000 3-5 1.5-6 ≤800 30 12-20 56
Φ2400×20000 3-5 1.5-5 ≤800 37 18-30 60
Φ2800×15000 3-5 1.5-5 ≤800 40 20-35 72.5
Φ2800×18000 3-5 1.5-5 ≤800 40 25-35 75
Φ3000×20000 3-5 1.5-5 ≤800 55 28-40 78
Φ3000×25000 3-5 1.5-5 ≤800 75 32-45 104.9


Relevant cases：

  • Sludge Alkaline Stabilization D

    Sludge lime disposal project in Yanjiao sewage plant Yanjiao sewage treatment plant is located in the southwest of Yanjiao Development Zone. The project site is located in Yanjiao sewage plant in the northwest corner of processing, on the west side of...
  • Heavy Metal Sludge Dehydration

    Brief introduction of process flow 1.Collection and transportation of sludge: trained personnel to clients collected sludge with iron and space bag packaging, and by the special transport of dangerous goods vehicle transport to the factory dangerous g...
